| No# | Description | Part's BOM NO# |
| A1 | Panel assembly | A050938001094-R0 |
| A2 | Enclosure assembly | 314020009R |
| A3 | Base assembly | A050699000225-A0 |
| Compressor assembly | A050901000165-R0 | |
| A4 | Condenser assembly | 372200154R |
| A5 | Evaporator assembly | 1050403000010-R0 |
| A6 | Electric box assembly | 314040011R |
| A7 | Fan frame assembly | A050999001722-R0 |
| A8 | Control panel | 973100486R |
| A9 | Upper foam of scroll assembly | 437100005R |
| A10 | Accessories assembly | 445100038R |
| 11 | Discharge ventilation warning label | 429300067R |
| 12 | Filter grill | 394050006 |
| 13 | Screw | 150010060R |
| 14 | Screw | 150010018R |
| 15 | Screw | 451010036R |
| 16 | Temperature sensor holder | 100280105R |
| 17 | Nether foam of scroll | 437100004R |
| 18 | Scroll right seal cotton | 383200113 |
| 19 | Discharge pipe of the compressor | A050405002988-R0 |
| 20 | Screw | A050101000032-R0 |
| 21 | PVC plastic | 150030021R |
| 22 | Screw | 150010018R |
| 23 | Suction pipe of compressor | A050405003326-R0 |
| 24 | Capillary assembly | A050908000964-R0 |
| 25 | 9# Retainning clasp | A050698000064-R0 |
| 26 | Screw | 150010018R |
| 27 | Pannel stator | 314120001R |
| 28 | Centrifugal fan | 394010010R |
| 29 | Motor | 320254061R |
| 30 | Axial flow fan | 394020015R |
